HPE ProLiant DL360 Gen10 Plus Network Choice
Back to Results
Main Specifications
Product Description
HPE ProLiant DL360 Gen10 Plus Network Choice - rack-mountable Xeon Silver 4310 2.1 GHz - 32 GB - SSD 2 x 480 GB
Type
Server - rack-mountable
Height (Rack Units)
1U
Localization
Region: United States, Canada
Server Scalability
2-way
Processor
1 x Intel Xeon Silver 4310 / 2.1 GHz (up to 3.3 GHz, (12-core)
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology
Cache Memory
18 MB L3 cache
Cache Per Processor
18 MB
RAM
32 GB (installed) / 4 TB (max) - DDR4 SDRAM
Storage Controller
RAID (SAS 12Gb/s) (HPE Smart Array P408i-a)
Server Storage Bays
Hot-swap 2.5"
Hard Drive
2 x SSD 480 GB - SATA 6Gb/s
Optical Storage
No optical drive
Networking
1GbE
Power Redundancy
Yes
Dimensions (WxDxH)
17.1 in x 29.2 in x 1.7 in
Weight
29.3 lbs
Manufacturer Selling Program
HPE Smart Choice
Environmental Standards
ENERGY STAR Qualified
Manufacturer Warranty
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type
Server
Product Form Factor
Rack-mountable - 1U
Built-in Devices
LED panel
Embedded Security
Trusted Platform Module (TPM) Security Chip
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localization
Region: United States, Canada
Expansion / Connectivity
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 - full-height ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - low-profile
Interfaces
3 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 1 x HPE iLO (1 in front) (service port) ¦ 1 x HPE iLO (1 rear) (management port) ¦ 1 x USB 2.0 (1 in front) ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear)
Manufacturer Warranty
Service & Support
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories
7 x high performance fans, SFF Easy Install Rail Kit, CPU standard heatsink
Compliant Standards
WEEE 2002/95/EC, TLS v1.2, ASHRAE Class A3, ASHRAE Class A4, Active Directory v1.0, ACPI 6.3, SMBIOS 3.2, Redfish API, Triple DES
Manufacturer Selling Program
HPE Smart Choice
RAM
Installed Size
32 GB (installed) / 4 TB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2667 MHz
Rated Memory Speed
3200 MHz
Form Factor
DIMM 288-pin
Slots
32 (total) / 31 (empty)
Features
Registered, dual rank, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
Configuration Features
1 x 32 GB
Networking
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Gigabit Ethernet, Ethernet, Fast Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Power
Device Type
Power supply - hot-plug
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 100-240 V
Power Provided
800 Watt
80 PLUS Certification
80 PLUS Platinum
Environmental Parameters
Min Operating Temperature
50 °F
Max Operating Temperature
95 °F
Humidity Range Operating
8 - 90% RH (non-condensing)
Storage Controller
Type
1 x RAID
Controller Interface Type
SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
Channel Qty
8
Buffer Size
2 GB
Cache Memory
Installed Size
L3 cache - 18 MB
Cache Per Processor
18 MB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Video Interfaces
VGA
Hard Drive
Type
SSD
Capacity
2 x 480 GB
Interface Type
SATA 6Gb/s
Dimensions & Weight
Width
17.1 in
Depth
29.2 in
Height
1.7 in
Weight
29.3 lbs
Processor / Chipset
CPU
Intel Xeon Silver 4310
Clock Speed
2.1 GHz
Max Turbo Speed
3.3 GHz
Number of Cores
12-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology
Chipset Type
Intel C621A
Sustainability Information
ENERGY STAR Certified
Yes
